Ai EasyVac 9 cfm 2-Stage Vacuum Pump with Mist Filter ETL/CE

The Ai EasyVac 9 is a dual-stage sliding-vane rotary vacuum pump, designed for high-performance vacuum applications. It provides precise and efficient vacuuming with enhanced capabilities, including a robust exhaust oil mist filter and versatile dual voltage compatibility.

Key Features

• High Pumping Rate:

  • 9 cfm (110V, 60Hz), 8 cfm (220V, 50/60Hz), making it suitable for a wide range of applications such as rotary evaporation, freeze drying, and vacuum distillation.

• Deep Vacuum Capability:

  • Achieves a vacuum level of 15 microns/millitorr, ensuring exceptional performance for demanding processes.

• Dual-Stage Operation:

  • Provides enhanced pumping efficiency and faster evacuation times compared to single-stage pumps.

• Exhaust Oil Mist Filter:

  • Includes a mist filter that reduces oil mist discharge, returns trapped pump oil to the pump, and ensures quieter operation.

• Free Accessories Included:

  • Comes with a KF25 flexible stainless steel bellow (3.3 ft), clamps, and centering rings—a $219 value.

• Switchable Voltage:

  • Compatible with 110V or 220V, 50/60Hz, allowing for flexibility across different power supplies.

Specifications:

• Electrical Requirements:
  • 110V/220V, 50/60Hz, single-phase, 750 watts (1 HP).
• Oil Volume:
  • 560 ml (0.6 quart).
• Vacuum Connections:
  • Vacuum connection: KF25/NW25 flange.
  • Exhaust filter connection: KF25/NW25 flange.
• Motor Speed:
  • 1720 rpm.
• Working Temperature Range:
  • -5°C to 60°C.
• Dimensions:
  • Pump: 16.5 x 6 x 11 inches (height is 16 inches with exhaust filter).
  • Shipping: 20 x 9 x 13 inches.
• Weight:
  • Pump: 37 lbs.
  • Shipping: 41 lbs.

Compliance and Warranty:

• ETL Tested to UL and CSA standards.
• CE Certified.
• 1-Year Warranty for peace of mind and reliable customer support.

Recommended Oil: Ultragrade 19, specifically formulated for rotary vane pumps to ensure smooth operation and long service life.

The Ai EasyVac 9 offers powerful performance, durability, and easy operation, making it a dependable choice for professionals who require a high-quality vacuum pump for laboratory or industrial settings. With its dual-stage design, deep vacuum capability, and included accessories, it provides excellent value and versatility.
