Ai SuperVac 11.3 cfm Corrosion-Resist 2-Stage Pump

Ai SuperVac 11.3 cfm Corrosion-Resistant 2-Stage Pump

The Ai SuperVac 11.3 cfm Commercial Grade Vacuum Pump is a high-performance, corrosion-resistant pump designed for continuous operation in demanding environments. With both 115V and 230V options available, this vacuum pump provides the capability to achieve ultimate vacuums down to 0.3 micron efficiently, making it ideal for rotary evaporators, distillation, and other lab processes that require a reliable and powerful vacuum source.

Key Features:

• UL Certified (115V Model): The 115V version of this pump is UL certified, ensuring it meets stringent safety standards for longevity and performance. This certification is required by many municipalities and provides a higher level of equipment safety.

• Powerful Performance: The pump features an impressive 11.3 cfm pumping rate for the 115V model (9.3 cfm for the 230V model). This ensures quick and effective evacuation of air, making it suitable for large-scale distillation or other processes that demand high vacuum levels.

• Corrosion-Resistant Design: Built to withstand prolonged use, this pump is designed with corrosion-resistant materials that ensure a longer service life, even when dealing with harsh solvents or environments.

• Ultimate Vacuum: It can reach an ultimate vacuum of 0.3 microns (without gas ballast) or 6 microns with the gas ballast engaged, offering versatile control over the vacuum level to suit different applications.

• Gas Ballast System: The multi-level gas ballast system allows you to control the vacuum process. By opening the ballast, the pump can pull a less deep and slower vacuum. This feature helps prevent the build-up of moisture, solvent, and contaminants inside the pump, ensuring smoother operation and easier maintenance.

• Low Noise and Quiet Operation: With a noise level of < 58 dB, the pump operates quietly, reducing disturbances in the lab environment while still providing powerful vacuum performance.

• Included Accessories: The pump comes with essential accessories, including a high-capacity exhaust oil mist filter, KF25 flexible stainless steel bellow (3.3 ft), clamps, and centering rings set—a total value of $469 included at no additional cost. These accessories improve both the pump's performance and ease of integration into your system.

Specifications:

• Electrical Requirements: 115V 60Hz or 230V 50/60Hz, single-phase, 1,100 watts
• Pumping Rate: 11.3 cfm (115V 60Hz) / 9.3 cfm (230V 50/60Hz)
• Ultimate Vacuum: 0.3 micron (without gas ballast), 6 micron (with gas ballast)
• Inlet/Outlet Connection: KF25/NW25 flange
• Oil Volume: 1.5 liters / 1.59 quarts
• Motor Speed: 1,715 rpm (60Hz) or 1,440 rpm (50Hz)
• Working Temperature: 5°C to 40°C
• Noise Level: < 58 dB
• Recommended Oil: Ultra-grade 19
• Warranty: Two years
• Dimensions: 21" x 7.5" x 12" (Unit), 36" x 10" x 17" (Shipping)
• Weight: 72 lbs (Unit), 90 lbs (Shipping)

Additional Benefits:

• Enhanced Safety: The inclusion of a high-capacity exhaust oil mist filter reduces the risk of airborne oil mist and noise, making the pump quieter and safer to use.
• Reliable for Long-Term Use: The SuperVac is engineered for long-term, continuous operation, making it ideal for labs with high-volume vacuum requirements.
• Versatile Application: It’s designed for a variety of applications, including use with rotary evaporators, solvent recovery systems, and other laboratory or industrial vacuum processes.

Conclusion:

The Ai SuperVac 11.3 cfm Corrosion-Resistant 2-Stage Pump is an excellent choice for labs and industrial settings requiring a reliable, high-performance vacuum. Its powerful performance, corrosion-resistant build, and low-maintenance features make it a trusted option for continuous vacuum operations. Additionally, the UL certification for the 115V model ensures a higher standard of safety and reliability. With all necessary fittings and accessories included, this pump offers great value for your vacuum needs.
