Benchmark Scientific TC9639 Thermal Cycler

The Benchmark TC9639 Thermal Cycler is specifically designed to meet the needs of laboratories requiring high-throughput thermal cycling. This advanced system delivers precise, reliable results through its user-friendly interface and versatile features.

Key Features:

Full-Color Touch Screen Interface: The large touch screen allows for intuitive operation. Access to the program wizard, library, and frequently used protocols is streamlined for quick and efficient setup.
Innovative Multi-Format Block: Eliminating the need for multiple interchangeable blocks, the TC9639 offers flexibility to accommodate:
- 96 x 0.2ml tubes
- 39 x 0.5ml tubes
- A 96-well plate
- 4 slides (using the 384-well block version)
Enhanced Lid Technology: The fully adjustable heated lid prevents condensation and sample evaporation. The system automatically shuts off when the lid temperature reaches 35°C for added safety.
Precision Temperature Control: With an operating range of 0°C to 100°C and an accuracy of ±0.2°C, the thermal cycler maintains optimal sample conditions using a proprietary algorithm that simulates real sample temperatures.
Unlimited Programming: Offers unlimited storage options for protocols, with flash drive compatibility and password-protected program access. Users can easily adjust time, temperature, and ramp rates.
Compact and Efficient Design: At just 16 lbs and measuring 10.2 x 14.2 x 9.9 inches, the unit fits seamlessly into laboratory spaces.

Technical Specifications:

Capacity:
- TC9639 Block: 96 x 0.2ml tubes/strips or 39 x 0.5ml tubes
- 384 Well Block: 1 x non-skirted 96-well plate or 1 x 384-well plate
Temperature Range: 0–100°C
Accuracy: ±0.2°C
Ramp Rate: Up to 4°C/second
Program Flexibility: Unlimited with flash drive storage
Power Supply: Universal, 75–275V, 50–60Hz
