Ai -30°C 10L Recirculating Chiller with 20L/Min Centrifugal Pump

The Ai C30-10-5L is a high-performance, compressor-based recirculating chiller designed for laboratory applications that require precise temperature control. This unit is ideal for cooling equipment such as rotary evaporators, analytical instrumentation, laser etching, ICP, vacuum systems, plasma etching, and jacketed reactors. It can also serve as a replacement for tap water cooling, offering a more sustainable and cost-effective solution.

Key Features

• Wide Temperature Range:

  • Temperature Range: Ambient to -30°C (no load condition), providing versatility for cooling below ambient temperatures.
  • Cooling Capacities:
    • 1,250W at 32°F/0°C.
    • 800W at 14°F/-10°C.
    • 300W at -4°F/-20°C.
    • 150W at -22°F/-30°C.

• Efficient Temperature Control:

  • Advanced PID digital temperature controller for accurate and stable temperature regulation.
  • Temperature Accuracy: ± 2°C, ensuring precision for critical lab processes.
  • Pt100 Temperature Sensor for reliable performance.

• Powerful and Durable Design:

  • Panasonic Compressor with high efficiency and reliability.
  • R410A Refrigerant, an eco-friendly refrigerant for improved performance.
  • Centrifugal Recirculating Pump with an output of 100 watts and a pumping speed of 20 L/min (5.3 gallon/min).
  • Maximum Head: 20 feet (6 meters).
  • Maximum Pressure: 5.8 psi.

• Stainless Steel Construction:

  • Type 304 stainless steel reservoir, polished for enhanced durability and corrosion resistance.
  • Chilling Fluid Connections: 3/8" hose barb x 2.
  • Reservoir Capacity: 10 liters (2.6 gallons).

• Built-In Fluid Filter and Pressure Gauge:

  • Built-in chilling fluid filter to protect the pump and prevent blockages.
  • Mechanical pressure gauge to display the coolant outlet pressure.

• Cost-Effective and Eco-Friendly:

  • Water consumption completely eliminated, making it a cost-saving and sustainable solution.
  • Built-in swivel casters for easy mobility in the lab.

• Safety Features:

  • Compressor over-temperature protection.
  • Compressor delay start protection.
  • Over-current protection and short circuit protection.

• Recommended for:

  • Ai 5L SolventVap rotary evaporators and similar rotary evaporators.
  • Suitable for jacketed reactors, laser etching, and vacuum systems.

Specifications

• Model: C30-10-5L
• Temperature Range: Ambient to -30°C (no load condition)
• Electrical Requirements:
  • 220V 60Hz 1-Phase, 1,100 watts (Note: Not compatible with 50Hz power).
• Cooling Capacity:
  • @32°F/0°C: 1,250W.
  • @14°F/-10°C: 800W.
  • @-4°F/-20°C: 300W.
  • @-22°F/-30°C: 150W.
• Compressor:
  • Make: Panasonic.
  • Power: 208-230V 60Hz 1-Phase.
  • Refrigerant: R410A.
• Recirculating Pump:
  • Type: Centrifugal.
  • Pumping Speed: 20 L/min (5.3 gallon/min).
  • Maximum Head: 20 feet (6 meters).
  • Maximum Pressure: 5.8 psi.
• Reservoir:
  • Material: Type 304 stainless steel, polished.
  • Capacity: 10 liters (2.6 gallons).
• Temperature Controller:
  • Type: Digital microprocessor PID controlled.
  • Display: Celsius (°C).
  • Temperature Accuracy: ± 2°C.
• Working Environment:
  • Temperature: -15°C/5°F to 25°C/77°F.
  • Humidity: Less than 66%.
• Swivel Casters: Built-in for mobility.
• Unit Dimensions: 17 x 26.5 x 27".
• Shipping Dimensions: 22 x 32 x 36".
• Unit Weight: 155 lbs.
• Shipping Weight: 210 lbs.
• Safety Features:
  • Compressor over-temp protection, delay start, over-current, and short circuit protection.
• Warranty: One year.

Applications

The Ai C30-10-5L is specifically recommended for use with Ai 5L SolventVap rotary evaporators, as well as for various laboratory cooling needs including jacketed reactors, laser etching, ICP, and vacuum systems. Its high cooling capacity and low-temperature range make it ideal for applications that require consistent and efficient temperature regulation.
