Ai SolventVap 5.3-Gallon/20L Rotary Evaporator w/ Motorized Lift

The Ai SolventVap 20L Rotary Evaporator is designed for high-capacity distillation needs, offering a combination of safety, performance, and efficiency. It is ETL tested to UL/CSA standards, ensuring high safety and durability. Ideal for labs requiring large-scale solvent evaporation, this model features a motorized lift, vertical glassware, and several advanced features that guarantee reliable results and safety.

Key Features:

• ETL Tested to UL/CSA Standards: Certification to these standards ensures the evaporator meets high safety and reliability expectations, critical for many industrial and laboratory environments.

• Plexiglass Water Bath Cover: A new plexiglass bath cover enhances safety and energy efficiency by improving temperature uniformity in the water bath and preventing heat and humidity loss.

• Solvent-Resistant PTFE & Viton Gaskets: Equipped with high-quality, solvent-resistant PTFE and Viton gaskets, this rotary evaporator is designed for extended use in challenging environments.

• Motorized Lift for Water Bath: The motorized water bath lift allows easy height adjustments for precise control during the evaporation process, ensuring smooth operation and ease of use.

• Efficient Condenser Design: Featuring main and auxiliary triple-circulating cold traps, the evaporator’s condensing surface area (9,480 cm² for the main condenser and 3,580 cm² for the auxiliary) ensures efficient condensation, even for high-boiling solvents.

• New Swivel Casters: Swivel casters with locks provide excellent mobility, making it easier to move the evaporator securely, even on uneven surfaces.

• Water Bath with Dual Heaters: The water bath features two heaters and operates from ambient temperature to 99°C (210°F), providing efficient heating. It also includes an over-temperature protector for safety.

• Easy-to-Use Digital Controls: The PID temperature controller offers precise control, stepping in 0.1°C increments. The digital speed and temperature displays make it easy to monitor and adjust settings.

• Continuous Feed System: This system allows solvent to be continuously drawn into the flask, maintaining operation without the need to pause.

• Glassware Set: The standard glassware set includes:

  • Evaporating Flask: 5.28 gallons (20 liters)
  • Receiving Flask: 2.64 gallons (10 liters)
  • Vertical Condenser: Efficient for distilling solvents with high boiling points.

• Vacuum System: Equipped with PTFE + Viton gaskets for superior sealing and a vacuum level of < 3 torrs, the system ensures safe and efficient operation under vacuum conditions.

Specifications:

• Electrical Requirements:

  • 220V, 50/60Hz, single-phase, 4300 watts, 20A
  • Rotation motor: 300 watts

• Evaporating Flask:

  • Capacity: 5.28 gallons (20 liters)
  • Maximum load: Not to exceed 60% of the flask’s capacity
  • Sealing flange: 4.9" diameter
  • Rotation speed: 10 to 130 rpm
  • Evaporating speed: 1 gallon/hour (water), 2 gallon/hour (alcohol)

• Receiving Flask:

  • Capacity: 2.64 gallons (10 liters)

• Condenser:

  • Glassware: Main + auxiliary triple-circulating cold traps (vertical)
  • Chilling fluid connection: 3/8" hose barb x 4
  • Condensing surface:
    • Main condenser: 9,480 cm² (10.2 sq ft)
    • Auxiliary condenser: 3,580 cm² (3.9 sq ft)

• Water Bath:

  • Temperature range: Ambient to 99°C (210°F)
  • Material: Stainless steel
  • Max water level: Not to exceed 1" from the top rim
  • Lifting: Motorized (7.5-inch maximum lift)
  • Number of heaters: Two
  • Drain port: One

• Vacuum System:

  • Vacuum level: < 3 torrs
  • Vacuum sealing: PTFE + Viton gaskets
  • Vacuum connection: 3/8" hose barb x 1

• Safety:

  • Dry-run protection, over-temperature shut-off, built-in circuit breakers

• Swivel Casters:

  • Four built-in with locks for stable positioning on uneven floors

• Shipping Weight:

  • Evaporator: 238 lbs
  • Glassware: 130 lbs

• Unit Dimensions:

  • Dimensions: 49 x 23.5 x 82.5" (WxDxH)
  • Shipping dimensions: 41 x 24 x 48" (evaporator), 34 x 29 x 33" (glassware)

• Compliance:

  • UL 61010-1: 2012 Ed.3
  • CSA C22.2# 61010-1-12: 2012 Ed.3
  • CE certification optional

Conclusion:

The Ai SolventVap 20L Rotary Evaporator is a premium choice for labs needing efficient, high-volume solvent evaporation. Its advanced features, such as the motorized lift, energy-efficient bath cover, and high-performance condenser, make it an excellent tool for industrial, pharmaceutical, and research laboratories. With a focus on safety, ease of use, and precise control, this rotary evaporator offers an excellent solution for large-scale distillation needs
